Clarinet System Configuration

• How to Set Up a Clarinet-Book configuration?
• Example of a single Clarinet-Book USB configuration
• Example of a dual Clarinet-Book USB configuration

How to Set Up a Clarinet-Book Configuration:

The 3 steps to build a protocol test platform:

• Select any PC equipped with built-in USB interfaces and running Windows 98 or Windows 2000.
• Install the Clarinet Run-time package (version 10.1 or greater)
• Plug the Clarinet-Book USB device into an available port. The Clarinet device is "bus-powered" by the USB network. The device should be sensed automatically, the driver should automatically load, and the device should then be ready for use.

Example of a Single Clarinet-Book USB Configuration

A single USB port notebook drives directly a Clarinet E1/T1 without any other connection than the USB cable.

Example of a Dual Clarinet-Book USB Configuration

Most desktops and some notebooks have a Host supporting two USB ports.  A dual USB port notebook drives directly two Clarinet E1/T1 without any other connection than the USB cable. Both devices are synchronized by the USB bus to provide a common time-stamping (accuracy of 1 ms).
