Clarinet-TTCN VOIP Interworking  ETS

Standard Features

VOIP ETS products Clarinet-System configuration Packaging Ordering information

Click to enlarge

VOIP ETS Products

Standard Reference

Clarinet ETS H246a: VOIP H246 ISUP/H323

• Protocol: ITU-T H.225 (11/2000) H.323 (11/2000) and ITU-T Recommendation Q.784.2 (1997)
• IUT: H323-ISUP gateway
• ATS:  Based on H246 standard of ITU-T written by ACACIA  .

Clarinet ETS Q1912a: VOIP ISUP/SIP

• Protocol: RFC3261 and ITU-T Recommendation Q.784.2 (1997)
• IUT: SIP-ISUP gateway
• ATS: Based on Q1912 standard of ITU-T  written by ACACIA  .

Clarinet ETS RFC3398a: VOIP ISUP/SIP

• Protocol: RFC3261 and ITU-T Recommendation Q.784.2 (1997)
• IUT: SIP-ISUP gateway
• ATS:  Based on RFC3398 standard of IETF written by ACACIA  .

Clarinet ETS H323-SIP: VOIP H323/SIP

• Protocol: ITU-T H.225 (11/2000) H.323 (11/2000) and RFC3261.
• IUT: H323-SIP gateway
• ATS:  Written by ACACIA  .

Description

• These ETS result from a compilation of the ATS (Abstract Test Suites) source included in ATS in TTCN-MP (IS-format) by the CLARINET-TTCN compiler.
• The ETS packages include the executable files of ETS and the templates of Clarinet file for a quick operation (Profiles, filters, Test cases list, PICS/PIXIT).

Clarinet-System configuration

Host Specifications

• USB interface + Windows 98 / Windows 2000 / Windows XP

Clarinet Specification

• To run an ETS, only the standard Clarinet RUN-TIME package is required
• The Clarinet RUN-TIME version should be at least the 10.5 version
• The Clarinet-profiles are used in User-Program behavior

Interface Under Test Specification

• The ETS can be run on different types of interfaces supported by CLARINET:
  • E1,T1 + Ethernet 10/100

Manager Options

• The features which generate and display a full TTCN-GR trace are included in the standard Clarinet RUN-TIME
• An access from the Clarinet profile-editor allows to manage directly both configuration files:
  • Test Cases list
  • PICS/PIXIT parameters.

Filter Options

• Filter includes TTCN functions to select the TTCN-GR trace events
• Programmable color attribute by type of events (Test-step, Test Case...)

Packaging

ETS

• All ETS are independent software packages delivered on the single CD-ROM Clarinet ETS
• The running of the software is controlled by the Clarinet security-key connected on parallel port
• The ETS installation and execution are subject to the general conditions of the ACACIA software use license.

ATS

• The ATS reference (mp file name) and ATS modifications are provided by Acacia in each package.
• The TTCN-GR test documentation corresponding to the ATS is available from standard organization.

Ordering Information

---
